Applications
Disclaimer: The applications in this section are shown in general terms. It is the
responsibility of the installer and designer to adhere to the local and national
codes when applying and installing the BPS.
Key
The following symbols and notations are found on the application diagrams in
this section.
Device labels
Symbol Description
V
Visible device
A
Audible device
G
Genesis visible/audible device
V
A
Visible or audible device
Device generating the Genesis sync pulse
Note: When this symbol appears on a BPS, the
Genesis sync pulse is controlled by DIP switch
SW2-5.
BPS modes (controlled by DIP switch)
Notation Description
COR Correlate mode
GM Genesis Master mode
ND Nondelayed mode
NAC settings (controlled by DIP switch)
Notation Description
SF Sense follow
CONT Continuous
Temp/Cal Temporal/California
AUX Auxiliary
