50 Remote Booster Power Supply Technical Reference Manual
Conventional audible or visible circuit to Genesis
notification
Figure 32: Conventional audible or visible circuit to Genesis notification
G
G G
GG
GG
GG
(11)
(10)
(1)
(2)
(3)
BPS
(6)
(7)
(8)
(9)
(4)
(5)
V/A
(1) Visible or audible circuit
(2) Sense 1
(3) Sense 2
(4) Mode: COR
(5) NACs: CONT
(6) NAC 1
(7) NAC 2
(8) NAC 3
(9) NAC 4
(10) To BPS, or EOL resistor
(11) To next device or EOL resistor
Note: The maximum number of BPSs that can be connected on a single NAC from sense circuit
to sense circuit is limited by available current and wire run length.
DIP switch settings for this application
BPS DIP switches can be set this way for the application to work correctly. Refer
to “Setting the DIP switches” for other options.
Figure 33: Switch settings
SW1 SW2
ON
1234
5
6
7
81234
5
6
7
8
