Bringing into Service
Page 16 of 42
3 Bringing into Service
Before you start up CryptoServer LAN, check whether all parts that belong to the delivery, as
listed in Chapter 1.5 of this manual, are present.
3.1 Ports and Interfaces on the Rear Side (AC Power Supply)
The CryptoServer LAN V4 with AC power supply might be supplied with slightly different ports
and interfaces on the rear side as shown in the following two figures, while the front panel
remains the same as in Figure 7 resp. Figure 9.
Figure 1: CryptoServer LAN V4 (AC) – Sockets and ports on the rear side (variant b)
Figure 2: CryptoServer LAN V4 (AC) – Sockets and ports on the rear side (variant c)
