Maintenance
Page 32 of 42
Figure 18: Power supply modules (AC) of the CryptoServer LAN V4
Figure 19: Power supply modules (DC) of the CryptoServer LAN V4
5. Use the handle a1/d1 to carefully pull the power supply module out of the CryptoServer
LAN's case.
6. Put the new power supply module in place.
a3 a1 a7
a5
a17
d3
d1
d5
d7
d15
