UTTERN D70 - Stern Anchor Windlass (Optional)

Uern D70 — System & Component Overview and Operaon
28
Before operang the windlass, make sure that the safely
lanyard is removed from the anchor
10. Stern Anchor Windlass (oponal)
The anchor windlass located at the stern of the boat assists with the anchoring of your boat by
automacally raising and lowering the anchor. The windlass can be operated from the helm or by a
handheld remote control.
Operaon
To operate the windlass, the windlass breaker, located on the baery switch panel, must be turned
ON. Operaon of the windlass at the helm is controlled by a momentary switch used to raise and
lower the anchor. Pushing down on the switch will lower the anchor, while pushing up on the switch
raises the anchor. Similarly, using the handheld remote control key fob, pushing on the down switch
will lower the anchor, while pushing the up on the switch will raise the anchor.
Built in to the stern windlass is an auto stop funcon that shuts the motor down once the anchor is
fully retracted and in the stored posion on the anchor roller. Mounted on the transom, the leaded
core rope goes through a mounng plate containing sensors. A red auto stop located at the end of the
rope will automacally shut the windlass o when it comes in contact with the sensors in the
mounng plate.
Anchor Windlass
Bow windlass
Windlass breaker
Windlass switch
Before operang the windlass, make sure that the safely
lanyard is removed from the anchor
clutch by turning the handle clockwise.
