DC Helm Panel
A bilge breaker — 3 Amp
Forward bilge breaker — 3 Amp
Horn breaker — 5 Amp
Navigaon lights breaker — 5 Amp
Courtesy lights breaker — 5 Amp
Trim tab breaker — 15 Amp
Windshield wiper — 10 Amp
Windshield washer — 5 Amp
12V outlets breaker — 10 Amp
Stereo breaker — 10 Amp
GPS / Electronics breaker — 10 Amp
Refer Breaker—10 Amp
Water pump — 10 Amp
Spare — 10 Amp
6. Electrical Schemacs
This owner’s manual contains electrical schemacs and wiring harness illustraons for your boat.
These electrical schemacs were generated by the Electrical Engineering Department for technical
reference and service technicians. Uern does not recommend that you aempt to work on the
boat’s electrical system yourself. Instead, we recommend that you take your boat to your local
authorized Uern dealer for service. Uern reserves the right to change or update the electrical
system on any model at any me without noce to the consumer and is not obligated to make any
updates to units built prior to the change.
