UTTERN D70 - Steering System and Engine Controls

29
Uern D70 — System & Component Overview and Operaon
11. Steering
Your boat comes equipped with a hydraulic steering system. The basic system for a single engine boat
contains a steering wheel, a hydraulic helm pump, a hydraulic steering cylinder, and hydraulic hoses. If
you purchase a Mercury Verado® six cylinder engine, the steering system includes an electric power
assisted steering pump to aid in the handling of the vessel.
Stern Anchor Windlass
Stern windlass
Stern eye
Stern anchor roller
Anchor
Windlass switch
Windlass breaker
Steering wheel
Helm pump
Hydraulic uid lines
Steering cylinder
Hydraulic Steering — Non -Tilt Helm
Remote
