Verado L6 Steering
Steering wheel
Tilt helm mechanism
Helm pump
Hydraulic uid lines
Steering cylinder
Hydraulic Steering — Tilt Helm
Steering wheel
Tilt helm mechanism
Helm pump
Hydraulic uid lines
Power assist pump
Operaon
When turning the steering wheel, the helm pump forces hydraulic uid through hoses to and from the
steering cylinder which is connected to the ller arm on the engine. The cylinder moves the ller arm
to either port and starboard, depending upon the direcon the steering wheel is turned.
Filling and Maintenance
A hydraulic steering system rarely needs to be relled aer the system is bled. However, if you ever
need to add uid to the system, refer to the steering manufacturer’s manual for complete
instrucons.
