Uern D70 — Electrical Systems
40
5. Fuses and Breakers
Your boat will either have fuses or breakers protecng the DC electrical system. If you have to replace
a fuse or electrical breaker, replace only with a fuse or breaker of the same rang. The amperage will
be marked on the fuse or breaker, and it is recommended that you carry spare fuses or breakers.
Use only fuses and breakers having the same amperage
rang as the original or as specied. Use of higher
amperage fuses or breakers is a re hazard.
If a fuse or breaker is replaced with one that has a lower amperage, it may not be sucient to carry
the electrical load of the equipment it is connected to and will cause nuisance failures. If a fuse or
breaker is replaced with one that has a higher amperage, it will not provide protecon against an
electrical malfuncon and could create a possible re hazard.
Baery Panel
Charge relay
Baery switch
CO monitor breaker — 5 Amp
Waste pump breaker—20 Amp
Spare breaker — 10 Amp
A bilge breaker—3 Amp
Forward bilge breaker—3 Amp
Stereo breaker—10 Amp
Main helm breaker—60 Amp
Macerator Switch
Fuses and breakers
ATO/ATC fuse Thermal breaker ANL fuse Magnec breaker
Panel locaon
