ISUALISATION AND SIGNALLING USING LED
A row of 8 red leds is fitted to the card, via which all the useful signals
for installation and usage are controlled.
D
uring the normal running of the control unit (NOT at the programming
stage), the meaning of each led can be found in the following table:
* Operating cycle: the 7 leds (light / delete) switch on
following the logic below:
• Led off
: control unit off
• Flashing light led at 2 Hz
: opening phase
• Permanent led
: control unit off with shutter open (if the
timer is on for automatic closing, the led turns off
briefly, every half a second)
• Flashing light led at 4 Hz
: closing phase
LED OFF ON
FLASHING led (combined with led 8)
Led 8 is OFF or ON Led 8 is BLINKING
1. start / up
On the start /up terminal,
the contact is open
On the start /up terminal,
the contact is closed
Start command received
from remote control
Writing in flash at the end
of the programming is failed
2. open / stop
On the open /stop
terminal, the contact is open
O
n the open / stop
terminal, the contact is
closed
S
top command received
from remote control or start
aborted due to stop being on
-
3
. auto / down
On the down terminal, the
contact is open
On the down terminal, the
contact is closed
Down command received
from remote control
-
4. photo
On the photo terminal, the
contact is open
On the photo terminal, the
contact is closed
Start aborted due to inter-
rupted photocell detection
Photocell test is failed
5. edge
On the edge terminal, the
contact is open
On the edge terminal, the
contact is closed
Start aborted due to pressed
edge detection
Edge test is failed
6. dm / fire
On the fire terminal, the
contact is open
On the fire terminal, the
contact is closed
Start aborted due to fire
alarm being on
-
7. light / canc - -
Light command received from
remote control or opening
cycle* phase indication or
remote control codes erasure
Remote control codes
erasure is failed
8. motor / test
/ error
The motor is not activated The motor is activated Error indication
