VAC V200 POSITIONER - Spare Parts List Feedback Options

92077r14
V200 POSITIONER
www.vacaccessories.com
11
3.2 Spare parts list Feedback options
Item Description Material Part no Qty
1 .......V200 Feedback Potentiometer 10K Kit .........................93006 .............. 1
(1 .......V200 Feedback Potentiometer 5K Kit ...........................93028 ..............  1)
(1 .......V200 Feedback Potentiometer 1K Kit ...........................93047 ..............  1)
1 ......Gearwheel 100-M0,5..............Plastic <PA> ..................90116 .............. 1
5 ......Terminal Block, Potentiometer ......................................91015 .............. 1
.......- Screw ISO 7045 MRX4x8-4 .Stainless Steel ..............7045040804 .... 1
6 ......Potentiometer Module 10K............................................93010 .............. 1
 (6 ......PotentiometerModule5K(Optional) .............................93030 ..............  1)
 (6 ......PotentiometerModule1K(Optional) .............................93031 ..............  1)
.......- Pot Arm mkII ........................ Zink ...............................90097 .............. 1
.......- Potentiometer 6186 R10K L1,0...................................6186R10K ....... 1
.......-Potentiometer6186R5KL1,0(Optional) ....................6186R5K ......... 1
.......-Potentiometer6186R1KL1,0(Optional) ....................6186R1K ......... 1
.......- Gearwheel 40-M0,5 .............Plastic <PA> ..................90115 .............. 1
.......- Tube spacer gear wheel....... Plastic <PA> ..................90119 .............. 1
.......- Circlip Gearwheel .................Stainless Steel ..............90067 .............. 1
.......- Pot Spring coil ......................Stainless Steel ..............90184 .............. 1
.......- Shaft mkII Pot Arm ............... Stainless Steel ..............90123 .............. 1
.......- Screw ISO 7045 MRX4x50 .. Stainless Steel ..............7045045050 .... 1
.......- Washer ISO 7089-4 ............. Stainless Steel ..............70894 .............. 1
.......- Flat cable with connector .....Plastic, brass, rubber ....92114 .............. 1
2 .......V200 Feedback 4-20mA Kit ..........................................93007 .............. 1
1 ......Gearwheel 100-M0,5..............Plastic <PA> ..................90116 .............. 1
5 ......4-20 mA module mkII ....................................................93123 .............. 1
.......- Screw ISO 7045 MRX4x8-4 .Stainless Steel ..............7045040804 .... 1
6 ......Potentiometer Module 10K............................................93010 .............. 1
.......- Pot Arm mkII ........................ Zink ...............................90097 .............. 1
.......- Potentiometer 6186 R10K L1,0...................................6186R10K ....... 1
.......- Gearwheel 40-M0,5 .............Plastic <PA> ..................90115 .............. 1
.......- Tube spacer gear wheel....... Plastic <PA> ..................90119 .............. 1
.......- Circlip Gearwheel .................Stainless Steel ..............90067 .............. 1
.......- Pot Spring coil ......................Stainless Steel ..............90184 .............. 1
.......- Shaft mkII Pot Arm ............... Stainless Steel ..............90123 .............. 1
.......- Screw ISO 7045 MRX4x50 .. Stainless Steel ..............7045045050 .... 1
.......- Washer ISO 7089-4 ............. Stainless Steel ..............70894 .............. 1
.......- Flat cable with connector .....Plastic, brass, rubber ....92114 .............. 1
3 .......V200 Feedback Mechanical Switch Kit .........................93004 .............. 1
1 ......Screw ISO 4762 M6x35 .........Stainless Steel ..............4762063535 .... 1
2 ......Switch Cam Module Mech ............................................93020 .............. 1
.......- Switch Shaft ......................... Zink ...............................90155 .............. 1
.......- Switch Cam mkII .................. Zink ...............................90157 .............. 2
.......- Switch Cam Clip mkII ...........Stainless Steel ..............90158 .............. 2
3 ......Switch Module Mechanical Switch ................................93023 .............. 1
.......- Switch Plate .........................Aluminum, Anodized .....90118 .............. 1
.......- Micro Switch V3 Camden ...........................................CMNS 2020D . 2
.......- Protection Plate V3 ..............Plastic <PA> ..................90086 .............. 1
.......- Terminal block, 3 terminals. ........................................92064 .............. 2
.......- Spacer DRN 3260x7.5 ........ Plastic <PA> ..................3260075 .......... 2
.......- Screw ISO 7045 MRX3x12 .. Steel Zinc plated ...........7045031212 .... 2
.......- Screw ISO 7045 MRX3x20 .. Steel Zinc plated ...........7045032020 .... 2
.......- Screw ISO 7045 MRX3x25 .. Steel Zinc plated ...........7045032525 .... 2
.......- Screw ISO 7045 MRX4x8-4 .Stainless Steel ..............7045040804 .... 3
.......- Washer ISO 7093-3 ............. Stainless Steel ..............709303 ............ 2
.......- Cable Blue AWG 16 L = 8” ..........................................92066 .............. 2
.......- Cable Black AWG 16 L= 8” .........................................92067 .............. 2
.......- Cable Brown AWG 16 L= 8” ........................................92068 .............. 2
Item Description Material Part no Qty
4 .......V200 Feedback Inductive Sensor Kit ............................93014 .............. 1
1 ......Screw ISO 4762 M6x35 .........Stainless Steel ..............4762063535 .... 1
2 ......Switch Cam Module Inductive Sensor ..........................93022 .............. 1
.......- Switch Shaft ......................... Zink ...............................90155 .............. 1
.......- Switch Cam mkII .................. Zink ...............................90157 .............. 2
.......- Switch Cam Clip mkII ...........Stainless Steel ..............90158 .............. 2
.......- Steel Pin 4x2 ........................Steel ...................................................... 2
3 ......SwitchModuleInductiveSensor(NAMUR) ..................93025 .............. 1
.......- Switch Plate .........................Aluminum, Anodized .....90118 .............. 1
.......-InductiveSensorNJ2-V3-N(NAMUR) ........................NJ2-V3_N ....... 2
.......- Terminal Block, 3 Terminals ........................................92064 .............. 2
.......- Spacer DRN 3260x7.5 ........ Plastic <PA> ..................3260075 .......... 2
.......- Screw ISO 7045 MRX3x12 .. Steel Zinc plated ...........7045031212 .... 2
.......- Screw ISO 7045 MRX3x20 .. Steel Zinc plated ...........7045032020 .... 2
.......- Screw ISO 7045 MRX3x25 .. Steel Zinc plated ...........7045032525 .... 2
.......- Screw ISO 7045 MRX4x8-4 .Stainless Steel ..............7045040804 .... 3
5 .......V200 Feedback Reed Switch Kit...................................93005 .............. 1
1 ......Screw ISO 4762 M6x35 .........Stainless Steel ..............4762063535 .... 1
2 ......Switch Cam Module Reed.............................................93021 .............. 1
.......- Switch Shaft ......................... Zink ...............................90155 .............. 1
.......- Switch Cam mkII .................. Zink ...............................90157 .............. 2
.......- Switch Cam Clip mkII ...........Stainless Steel ..............90158 .............. 2
.......- Magnet Neodym Ø4x2 ......... Neodym .........................43-0940-10 ..... 2
3 ......Switch Module Reed Switch..........................................93024 .............. 1
.......- Switch Plate .........................Aluminum, Anodized .....90118 .............. 1
.......- Reed Switch Hamlin ....................................................59145 3S02A .. 2
.......- Spacer DRN 3260x7.5 ......... Plastic <PA> ..................3260075 .......... 2
.......- Spacer DRM 3260x2 ............Brass Ni plated ..............326002 ............ 2
.......- Spacer DRN 3260x6 ............ Brass Ni plated ..............326006 ............ 2
.......- Terminal Block, 3 Terminals ........................................92064 .............. 2
.......- Screw ISO 7045 MRX3x12 .. Steel Zinc plated ...........7045031212 .... 2
.......- Screw ISO 7045 MRX3x20 .. Steel Zinc plated ...........7045032020 .... 4
.......- Screw ISO 7045 MRX4x8-4 .Stainless Steel ..............7045040804 .... 3
.......- Washer ISO 7093-3 ............. Stainless Steel ..............709303 ............ 2
6 .......V200 Feedback Mech+4-20mA Kit ...............................93011 .............. 1
3 ......- V200 Feedback Mechanical Switch Kit .......................93004 .............. 1
2 ......- V200 Feedback 4-20mA Kit ........................................93007 .............. 1
7 .......V200 Feedback Inductive Sensor +4-20mA Kit ............93015 .............. 1
4 ......- V200 Feedback Inductive Sensor Kit ..........................93014 .............. 1
2 ......- V200 Feedback 4-20mA Kit ........................................93007 .............. 1
8 .......V200 Feedback Reed+4-20mA Kit ................................93012 .............. 1
5 ......- V200 Feedback Reed Switch Kit ................................93005 .............. 1
2 ......- V200 Feedback 4-20mA Kit ........................................93007 .............. 1
