1 INTRODUCTION
1.1 Principle of operation
The V200 feedback options allows for accurate
positionfeedback,whereon-o󰀨(open/closed)
indication(switches)orcontinuous4-20mA
transmission(orsimplepotentiometer)isrequired.
Anyfeedbackmodulecanbefactoryoreldinstalled
inside the V200 positioner housing with no special
parts or mounting brackets. This creates a very
compact and simple package that is completely
sealed.
The various feedback options are connected to the
positionermaindriveshaft(1)whichisconnectedto
the actuator shaft via the positioner spindle, assisting
inamoredirectandaccurateactuator/valvemonitoring.
A position change moves the V200 spindle and switch
cam(2)foron-o󰀨(oropen/closed)indication.
The4-20mApositiontransmittermkII(3)respondsto
changesproportionallyintheactuator/valvepackage.
It is recommended that the V200 positioner be
calibrated before installing feedback options.
CAUTION:
Beware of moving parts
when positioner is operated!
1.3 Safety instruction
CAUTION: Beware of parts with live voltage!
A voltage, which is normally not dangerous, is supplied to the positioner. Avoid touch-
ing live parts and bare wires as well as short circuiting live parts and the housing.
1.2 Product identication
TheV200identicationtags,Serialnumbertag(1),product-
modeltag(2)andfeedbackoptiontag(3),areplacedasshown.
The product model tag contains information on control signal,
maximum working pressure and temperature ranges.
Other information can be shown depending on the model.
Not for use in Hazardous locations.
Feedback options described in this manual
are for for General purpose only.
1
3
2
