Vacon 10 User Instruction

5 • vacon vacon-adp-mcaa adapter
Tel. +358 (0)201 2121 • Fax +358 (0)201 212205
3.2 Connecting Vacon 10 to a PC with the MCAA adapter
1
Make sure that Vacon 10 is powered off.
2
Remove the rubber plug covering the connector port of the drive, see
below:
3
Connect the MCAA adapter to the drive, see below:
4
Connect the PC cable to the adapter and to your PC.
