Set-up 4
0020261188_00 ecoTEC plus Installation and maintenance instructions 9
4.7 Wall-mounting the product
1. Check the load-bearing capacity of the wall.
2. Note the total weight of the product.
3. Only use fixing material that is permitted for the wall.
4. If required, ensure that mounting apparatus on-site has
sufficient load-bearing capacity.
5. Wall-mount the product as described.
4.8 Removing/installing the front casing
4.8.1 Removing the front casing
1. Undo the screw (A).
2. Push in both retaining clips (B) so that the front casing
is released.
3. Pull the front casing forwards at the bottom edge (C).
4. Lift the front casing upwards from the bracket (D).
4.8.2 Installing the front casing
1. Place the front casing (A) on the upper retainer (B).
2. Hinge the front casing down in the direction of the
product (C).
3. Push the front casing onto the product and, in doing so,
ensure that the insulation is not damaged (D).
4. Let the retaining clips on the front casing snap into
place.
5. Tighten the screw (E) in order to secure the front cas-
ing.
