Filtering

1282 0501

hex

Enable of disable

measurement ﬁltering using

the user-deﬁned ﬁltering

factor (register 031A

hex

)

16-bit boolean 0 = O

1 = On

Communication

1537 0600

hex

Modbus address 16-bit integer 1 ... 247

Default: 240

1538 0601

hex

Bit rate enum 0 = 300

1 = 600

2 = 1200

3 = 2400

4 = 4800

5 = 9600

6 = 19200

7 = 38400

8 = 57600

9 = 115200

1539 0602

hex

Parity, data, stop bits enum 0 = None, 8, 1

1 = None, 8, 2

2 = Even, 8, 1

3 = Even, 8, 2

4 = Odd, 8, 1

5 = Odd, 8, 2

(default: 1 = None, 8, 2)

1540 0603

hex

Response delay 16-bit integer Unit: ms

Range: 0 ... 1000

Functions

1285 0504

hex

Start purge 16-bit function

status

When writing to

1 = Start purge

1542 0605

hex

Restart device 16-bit function

status

When writing to

1 = Restart the device

HMP Series with MMP8 and TMP1 User Guide M212022EN-F
