Property Description/Value

Current consumption 10 mA typical

Digital output RS-485, non-isolated

Protocols Modbus RTU

Output parameters Temperature (°C)

Water vapor saturation pressure (hPa)

Table 56 TMP1 compliance

Property Value/Description

EU directives EMC Directive (2014/30/EU)

RoHS Directive (2011/65/EU)

EMC compatibility EN 61326‑1, industrial environment

Compliance marks CE, China RoHS, RCM, WEEE

Table 57 TMP1 mechanical speciﬁcations

Property Description/Value

Connector M12 5-pin A-coded male

Weight 224 g (7.9 oz)

Materials

Probe AISI 316L

Probe body AISI 316L

Cable jacket FEP

Chapter 9 – Technical data
