Vaisala HMP7 - Figure 20 Mounting DTR502 B on a Pole Mast

To Next Page

To Previous Page

Figure 20 Mounting DTR502B on a pole mast

Pole mast with diameter 30 … 60 mm (1.2 … 2.3 in)

2 Support plate

3 Fastening ring

4 Probe head

5 Sensor head support

1. Mount the solar radiation shield in the measurement location using the provided

mounting accessories, screws, and washers. You can mount the radiation shield to a pole

mast as shown in Figure 20 (page 39), or to a horizontal beam directly from its support

plate.

Chapter 4 – Installation
