Even if condensation prevention has been turned on, probe heating is not active if

supply voltage is below 18 V DC. For example, this is the case when HMP7 probe is

connected to Insight software using the Indigo USB Adapter.

More information

‣

Conﬁguring condensation prevention (page 42)
