Valeo DD 430 - Lower Evaporator Components (C-ES)

EQUIPMENT DESCRIPTION DD 430
NOTE: visit www.reparts.com to consult the complete parts catalog.
2.4- Components of Lower Evaporator Models C - ES
10
1
9
10
11
2 3
7
6
84
13
14
12
5
WITHOUT HEATING WITH HEATING
1 Lower Evaporator Model 061-00190-000 061-00248-000
1
2 Lower Evaporator Capillary Tube Coil
1
3 Lower Heating Capillary Tube Coil 006-00184-000
1
4 Expansion Valve
1
5 Evaporator Electric Wiring Harness 016-00323-000 016-00323-001
1
6 Radial Fan Clip
6
7 Radial Fan 24V
3
8 Liquid Line Tube
1
9 Lower Evaporator Duct
1
10 Left Hand End Cover 040-00778-000 040-00778-002
1
11 Right Hand End Cover
1
12 Fan End Cover
1
13 Capillary Tube Sealing Sheet
1
14 Lower Evaporator Tray 1
040-00779-000
040-00780-000
040-00781-000
043-00198-001
012-00081-000
017-00309-000
021-00014-000
031-00286-000
034-00277-000
ITEM DESCRIPTION
CODE
QUANT.
006-00124-000
47
