EQUIPMENT DESCRIPTION DD 430
NOTE: visit www.reparts.com to consult the complete parts catalog.
2.5- Components of Parcel Rack Lower Evaporator Model FS
1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
LEFT HAND RIGHT HAND
1
Parcel Rack Lower Evaporator Module
DD
061-00284-000 061-00292-000 1
2
Parcel Tack Lower Evaporator Capillary
Tube Coil DD
006-00104-001 006-00104-002 1
3
Lower Evaporator Heating Capillary Tube
Coil
006-00147-001 006-00147-002 1
4 Radial Fan 24V 1070 M3/H – SPAL VLL 1
5
Lower Evaporator Liquid Line Tube
Assembly
1
6 Lower Evaporator Suction Tube Assembly 1
7
Cond. Water Tray Assembly + Lower
Evaporator Drain
1
8 Lower Evaporator Air Return End Cover 040-02671-001 040-02671-000 1
9 Evaporator Fan Clip 2
10 Lower Evaporator Attachment Support 040-02666-000 040-02666-001 1
11 Temperature Sensor GLOBUS S-030 1
12 Anti-freezing Thermostat 1
13 Bracket Body STAUFF Group 1: Ø 9.5 1
14 Bracket Body STAUFF Group 2: 16mm 1
15 Lower Evaporator Upper End Cover 1
16
Lower Evaporator Electric Wiring
Harness 24V
016-00440-000 016-00440-001 1
010-00016-000
017-00351-000
017-00342-000
040-02650-000
031-00520-000
031-00518-000
046-00031-000
017-00309-000
007-00042-000
ITEM DESCRIPTION
CODE
QUANT.
021-00014-000
48
