BUS BODY ELECTRONICS

2.8 Additional component

Press button, for additional component on / off

➔ LED illuminates when additional component is switched

on, if an additional component is present (Figure 15).

The button controls output 7, to which the additional compo-

nent is connected.

The functions runs independently of the heating / cooling mode.

Figure 15 – SC410 additional component

switched on
