10- Service parts
1. Compressor body service kits, sets and parts
2. Oil
Item* Part name Reference Quantity
OVERHAUL KIT
(O-RING SET + GASKET SET + SHAFT SEAL)
5699306221 -
O-RING SET 569920-4420 -
15,20 O-ring body (front & rear head) 569300-8900 n=2
18 O-ring drain 569300-4000 n=1
GASKET SET 569941-1921 -
12 Gasket front head 569310-6000 n=1
23 Gasket rear head 569310-6100 n=1
9 Gasket (bolt) 7 per set 569310-6200 n=7
SHAFT SEAL (for service) - -
11 Shaft seal 569942-1320 n=1
OTHER COMPRESSOR PARTS - -
13 Valve plate assy (front) 561420-2120 n=1
22 Valve plate assy (rear) 561420-2020 n=1
14,21 Suction valve 561410-1300 n=2
Item Part name Reference Quantity
- ZXL 100PG 569900-0600 250 cc
* see product description - Exploded view p.7
