※The above specifications may vary with the compressor.
TYPE Electromagnetic single-plate dry clutch
RATED VOLTAGE 24V DC or 12 V DC
POWER CONSUMPTION 48 W maximum
STATIC TORQUE 78 N·m {8.0 kgf·m, 58 lbf·ft}
DIRECTION OF ROTATION Clockwise, viewed from clutch
WEIGHT Approx 4.5 kg {10 lb}
V-BELT TYPE V-groove (A or B) or V-ribbed (PK)
1- Product description - Magnetic clutch
Specifications*
