Appendix 2 Cable Wiring Schemes
Wiring colours are correct at the time the manual was printed. However, it is advised that continuity checks
are performed prior to all terminations.
106 Fish SubConn Connector
10 Way SubConn Connector
Pin
Function
MCBH10F +DLSA-F – Locking Sleeve
2
External Supply
8
RS232 into Fish
1
(Connect to Pin 9)
Ground
7
RS232 out of Fish
10
Sea Switch
Y Lead
End 1: SubConn
MCIL10M+DLSA-M4M
End 2:
End 3:
9 Way D Socket RS 465-362
with hood (RS 480-119)
Function
Pin
Pin
10
Black 4mm Plug
RS 444-797
(Join in plug)
Internal Battery Enable
1
-V Supply
2
Red 4mm Plug
RS 444-832
+V Supply
3
RS422 TXA (N.C.)
4
RS422 TXB (N.C.)
5
RS422 RXA (N.C.)
6
RS422 RXB (N.C.)
7
2
RS232 TX
(out of unit)
8
3
RS232 RX
(in to unit)
9
1, 5, 6, 8, 9 - SHELL
RS232 GND
