8008 Comms & Power Lead (SubConn to Milspec)
End1 - 10WAY SubConn
End 2 -10 Way Milspec
Function
Connector
Pin
Pin
Connector
MCOM10M+ OMBA Boot+
DLSA Locking Sleeve
1
C
LMH 06F 1210PN
-V
2
A
+V
RS422 TXA
RS422 TXB
RS422 RXA
RS422 RXB
7
D
RS232 TX
8
B
RS232 RX
9
H
RS232 GND
10 (Link to Pin1)
