Valeport 106 - Surface Unit Connector Wiring; Deck Lead Wiring

0106804 b - Model 106 Current Meter - Operating Manual
@ 2019 – Valeport Ltd
Page | 25
Digital Current Loop / 8008 Surface Unit Connectors
DC Input
Connector Type
Pin
Wire
3 Way Plug 0833 MNO
A
+V in
B
0V in
C
N/C
RS232
Connector Type
Pin
Wire
RS232 Out 4 Way Skt
A
N/C
B
RS232 in
C
Common
D
RS232 out
Deck Lead
Fish Input
12-10-FNO
Pin
Wire
A
EXT Power in +VE
B
N/C
C
EXT Power in GND
D
N/C
E
N/C
F
N/C
G
N/C
H
Link to J
J
Link to H
K
N/C
