REMOVAL OF CONDENSING WATER
NOTE
The Vallox Silent Klick siphon package is delivered with the
unit. Installation instructions for the siphon are enclosed with
the packaging, and can also be found online at www.vallox.
com. When the alternative siphon installation method is used,
the ring seal and the locking part must be moved to the pipe
connection part that is mounted on the wall.
INSTALLATION
Dimensioning figure and space required for installation of the Vallox
Silent Klick siphon
Space required by the alternative Vallox Silent Klick siphon installation
method (elbow)
Vallox 096 MV
R
L
55
R
L
121
143
143
121
L
140
140
R
141
43
43
180180
141
141
141
75
28
28
38
Vallox 110 MV Vallox 145 MV
Vallox 096 MV Vallox 110 MV Vallox 145 MV
