12
Vallox 110 MV
INSTALLATION
28
678
706
455
472
638
111
325
112
390
160
478
L
1
2
3
4
455
472
638
111
325
112
390
160
478
R
1
2
3
4
142
4
429
473
160
160
1
2
3
4
5
6
7
8
9
10
A
B
3
4
3
12
5
6
3
4
3
1 2
5
6
1. Extract air fan
(behind the protective cover)
2. Supply air fan
(behind the extract air duct)
3. Fine filter for supply air
4. Heat recovery cell
5. Bypass damper of the HR cell
R model in the figure.
In the L model, the parts are mirrored
6. Coarse filter for supply air
7. Coarse filter for extract air
8. Post-heating resistor
(behind the extract air duct)
9. Safety switch
10. Additional heating resistor
(behind the extract air duct)
Air flow measurement points
A Supply air
B Extract air
Measurement points after the outlet
collar. The fan curves indicate the
total pressure accounted for by duct
losses.
Locations of supports for HR cell
L modelR model
Duct outlets
Inner diameter of the outlet collar: 160mm
1. Supply air from the unit to the apartment
2. Extract air from the apartment to the unit
3. Exhaust air flowing outdoors from the unit
4. Outdoor air to the unit
1. Supply air
2. Extract air
3. Coarse filter
4. Fine filter
5. Upper support for HR cell
6. Lower support for the HR cell
Main parts Dimensions and duct outlets
Dimensions
