Vallox A3712-1 Manual

29
© Vallox Oy - All rights reserved
1
2
3
1
2
19
15
24
25
16
18
26
27
28
6
4
5
20
21
14
13
12
11
22
23
10
9
8
7
17
29
30
Vallox 110 MV
NO. PART CODE
NO. PART CODE
NO. PART CODE
1.
Supply / extract air
fan
1108800 12. Bypass duct assembly 21.
Additional heating resistor
900W
2. Fan 935415 R model 3447200 R model 942210
3.
Wall mounting plate
(optional)
3080700 L model 3447201 L model 942211
4.
Siphon Vallox Silent
Klick
3494701 13. Damper motor 930620 22. Door 3447300
5.
Coarse filter for
supply air
978042 14. Extract air outlet 985025 23. Door latch 3355900
6.
Fine filter for supply
air
978157 15.
Internal humidity and
carbon dioxide sensor
4107982 24. NTC sensor kit 3457900
7.
Lower support for
HR cell
3450100 16. Motherboard 949032-1 25.
Glass tube fuse 63mA slow
5x20mm
952490
8.
HR cell (aluminium)
HR cell (enthalpy)
933160
933170
17. Safety switch 948377 26.
MyVallox Control panel
MyVallox Touch control panel
949033
949090
9.
Upper support for
HR cell
3426600 18. Connection box 3526700 27.
MyVallox humidity sensor
(optional)
946149
10. Filter stand 3426800 19. RJ45 extension cable 952196 28.
MyVallox carbon dioxide sensor
(optional)
949111
11.
Coarse filter for
extract air
978043 20.
Post-heating resistor
900W
29. MyVallox VOC sensor (optional) 949112
R model 942211 30.
Ceiling bushing for electric wires
Ceiling feed-through seal
950445
950446
L model 942210
