Valor 203 User Manual

INSTALLATION GUIDE – 203 DISPLAY
www.valortpms.com
12
-203 Tire Pressure Monitoring System
1
2
3
4
5
6
89.6 88.0 88.8
3.1 Reading the Integrated Display
The unit displays tire pressure and temperature values of the tires being monitored.
On the right side of the display is a list of numbers indicating axle position. Up to 6 axles are available on the
203 Display. Tire pressure or temperature values are displayed left to right according to tire location.
Pressure and temperature values do not appear on screen at the same time. If the PSI indicator is illuminated,
the unit displays tire pressure, if the ºF indicator light is illuminated, the unit displays tire temperature values.
PART 3 : Reading The Display
PRESSURE
(PSI)
TEMPERATURE
ºF
AXLESSLOW LEAK
WARNING
MAJOR ISSUE
WARNING
