INSTALLATION GUIDE – 203 DISPLAY
www.valortpms.com
8
1.7 Installing Tractor ID Box
1.8 Installing Gen II Trailer Box
1.9 Programming Gen II Trailer Box
In order for the Trailer to communicate with a Tractor, an ID box is required. Attach the ID Box (if supplied) on
the back of the Tractor (externally). Please note, direct line of sight is needed between Tractor and Trailer ID
boxes with the read range between 1 and 1.6 meters.
For sensor programming please refer to the instructions: “How to Program Valor Gen II Trailer Box” provided
by your Valor Sales Representative.
Suggested Tire Locations for Programming:
Trailer (2 axle, 8-Wheel)
1A – Left Outside
1B – Left Inside
1C – Right Inside
1D – Right Outside
2A – Left Outside
2B – Left Inside
2C – Right Inside
2D – Right Outside
1. Attach the Trailer Box to the front of the trailer.
2. Connect the harness to the 12-pin Deutsch connector on the Gen II Trailer Box and wire to power source.
(Red-positive, Black-negative)
3. Attach antennas (see section 1.9.1)
PART 1 : System Installation
