Valor 203 User Manual

INSTALLATION GUIDE – 203 DISPLAY
www.valortpms.com
9
1.9.1 Installing Antennas
1. Locate a place between the trailer wheels. Attach the 12m antenna pointing downwards. Be sure not to
locate near where a moving part will be in contact with the antenna.
2. Run the cable from the rear of the trailer to the front and connect to the antenna connector on the Tractor
ID Box. Using wire ties, attach the cable to the vehicle’s wiring harness (normally runs along the frame).
3. If there is any extra cable, loop up and wire tie out of the way making sure it does not interfere with any
other item on the truck
PART 1 : System Installation

Valor 203 Specifications

General

Capacity	200 g
Readability	0.001 g
Display	LCD
Power	AC Adapter (Included)
Units	g
Measurement Range	0 - 200 g
Dimensions	196 x 223 x 73 mm
Weight	0.9 kg
