Valor 546LFB ZC Portrait Ledgeview Front User Manual

2
12-3/4”
11”
1-1/2” max.
1/2” min.
6-5/8”
dia.
4”
Top
Outlet
Mantel
‘A’
ZC Stand-os
12-3/4”
11”
4”
Do not put
furniture or objects
within 36” of front
of appliance
1/2”
‘B’
32”
25-1/4”
21-5/8”
22-7/16”
20”
32-1/8”
26”
Insulation
2” sidewall minimum
clearance
1-1/2” between bottom of trim
and bottom of appliance
Kit Contents
546 ZC
1 Backing Frame assembly
1 Backing plate
1 Ledgeview Front assembly
1 Heat Exchanger Cover
1 Ceiling Panel
1 ZC Baffl e
1 Barrier Screen (fi tted)
2 Stand Offs
1 Insulation
2 Stud Brackets
1 Cement board
2 Screws #8 x 3/8 tapping pn hd ph
8 Screws #8 x 1/2” black
4 Screws #8 x 1/2” s/t black
Dimensions and Clearances
Heat
exchanger
cover
Hardieboard
Stud brackets (2)
ZC bae
Stand o brackets
Backing plate
26”
W x 32-1/8” H
Backing frame
assembly
Ledgeview Front with
Barrier screen
Insulation
Ceiling
panel
Mantel Clearances
Mantel Depth ‘A’
0–6”
(0–152 mm)
8”
(203 mm)
10”
(254 mm)
12”
(305 mm)
Mantel Height ‘B’
4”
(102 mm)
8”
(203 mm)
10”
(254 mm)
12”
(305 mm)
