Valor G4 Series User Manual

Spare Parts
Description
Part
Number
1 AutoFire Exhaust slide assembly 4006540
2 Exhaust Slide Gasket 4001662
3 Valve access cover 4002289
4 Side brick anchors (2) 4001283
5 LH Explosion relief assembly 4001286
6 RH Explosion relief assembly 4001287
7 Access panel gasket 4002664
8 Access plate 4002510
9 Shrouds (2) 4002446
10 Window frame assembly (inc. glass) 4004463S
11 Hot glass warning plate 4003093
12 Ceramic burner platform 4004044
13
Burner module assembly (natural gas) 4006261S
Burner module assembly (propane gas) 4004046S
14 Top gasket 4002403
15 Side gaskets (2) 4002404
16 Bottom gasket 4002405
17 Thermocouple/pilot sealing plate 4002700
18 Single pipe sealing plate 4004338
19 Air shutter 4002590
20
Injector elbow #850 (natural gas) 9730010
Injector elbow #300 (propane gas) 9730035
21 Injector nut 420K464
22 Pilot Shield 4003018AH
23
Pilot Assembly (natural gas) 4001690
Pilot Assembly (propane gas) 4001691
24 Thermocouple 4000061
25
Pilot Injector #51 (natural gas) 4000735
Pilot Injector #30 (propane gas) 4000736
26 Pilot Hood 2 Flame 4000730
27 Extended Nut 4001855
28 Electrode 4001856
29 Main burner pipe assembly 4004047
30 Thermocouple interrupter 4001037
31
GV60 valve assembly (natural gas) 4006260S
GV60 valve assembly (propane gas) 4004284S
32 36” fl ex pipe 4002475
33 Ignition Cable 4001039
34 Insulation sleeve for ignition cable 4002244
35 Switch with Cable 4001036
36 Cable Interrupter 4001035
37 Receiver MAX (GX) 4002422
38 Wiring Harness 4001187
Description
Part
Number
39 Auxiliary battery holder & cable
a Battery holder 4006553
b Battery holder cable 1500 mm 4006552
40 Handset GV60 MAX 4002251
41 Remote Control Wall Holder 9000008
42 Log Set Complete 4004043
43 RH middle log 4002683
44 RH base log 4002685
45 Center base log 4002686
46 LH base log 4002684
47 LH middle log 4004052
48 LH cross log 4004050
49 Rear log 4004051
50 RH cross log 4004049
51 Liner panels—complete set
a Ledgestone 786LSLV2
b Refl ective glass 787RGL
c Ceramic fl uted black 788FBLV2
d Valor red brick 789VRLV2
52 Top panel
a Ledgestone 4002368
b Ceramic black 4002374
c Ceramic black 4002374
d Valor red brick 4002385
53 Rear panel
a Ledgestone 4004267
b Refl ective glass 4004707
b Rear fi ller panel 4004799
c
Ceramic fl uted black
4004268
d Valor red brick 4004266
54 Left side panel
a Ledgestone 4002365
b Refl ective glass 4004708
b Filler panel 4002776
c Ceramic fl uted black 4002377
d Valor red brick 4002382
55 Right side panel
a Ledgestone 4002366
b Refl ective glass 4004709
b Filler panel 4002776
c Ceramic fl uted black 4002378
d Valor red brick 4002383
56 GV60 Valve repair kit 4004544
OWNER’S
INFORMATION
41

Valor G4 Series Specifications

General

Venting	Direct Vent
Log Set Material	Ceramic Fiber
Fuel Type	Natural Gas or Propane
Ignition Type	Electronic
Warranty	Limited Lifetime
