12
Designed and Manufactured by / for Miles Industries Ltd.
190 – 2255 Dollarton Highway, North Vancouver, BC, CANADA V7H 3B1
Tel. 604-984-3496 Fax 604-984-0246 www.valor replaces.com
Because our policy is one of constant development and improvement, details may vary slightly from those given in this publication.
Description Part no.
LDK1 48” Quad Hot Air Plenum Kit
48” x 2” quad plenum 4005476
5” take-off collars (4) 4005478
Top mounting bracket/standoffs (2) 4005566
LDK2 48” Outlet Frame Kit for LDK1
Aux Frame-SPL 48” x 2” white 4005612
LDK3 14” Double Hot Air Plenums Kit
14” x 6” double plenums (2) 4005464
5” take-off collars (4) 4005478
DABL-00-C-SPL 14” x 6” Grilles
white (2)
4005614
Top mounting bracket/standoffs (2) 4005566
LDK4 38” Quad Hot Air Plenum Kit
38” x 2” quad plenum 4005477
5” take-off collars (4) 4005478
Top mounting bracket/standoffs (2) 4005566
LDK5 38” Outlet Frame Kit for LDK4
Aux Frame-SPL 38” x 2” white 4005613
LDK6 5” Aluminum 2-ply Flex Kit
5” dia 10’ (uncompressed)
aluminum chimney liners (2)
4005635
4.5” - 6.5” ss gear clamps (8) 4005642
Repair Parts List
LDK1
LDK4
LDK3
LDK5
LDK6
LDK2
Each LDK kit is sold separately.
