Valor LINEAR SERIES Installation Instructions

3
Suggested Confi gurations
Front wall outlet using LDK1 or LDK4
Rear wall outlet using LDK1 or LDK4
Note: Fireplace vent may confl ict with
plenum. Offset vent around plenum.
Corner installation with front or rear wall outlet
using LDK1, LDK3 or LDK4
Side wall outlets using LDK3
Rear wall outlets using LDK3
WARNING
This duct kit is approved for horizontal
discharge ONLY. DO NOT install ple-
num in fl oor or ceiling.
DO NOT DISCHARGE OUTDOORS.
!
