19
Schéma des connexions
Interrupteur mural
Connecteur
Antenne
Câble de l’électrode
Bloc interrupteur
Câble de 8 ls
Marche
Arrêt
Commutateur de réinitialisation
Veilleuse
Soupape combinée
4 piles AA
Compartiment à piles
Étincelle
Récepteur
Étincelle
Thermocourant
Bloc interrupteur
Interrupteur marche-arrêt
Interrupteur
marche-arrêt
Bouton principal de la soupape
Bouton manuel
Terminal
rouge
Schéma des connexions GV60
