8
WARNING
DO NOT TOUCH THE BARRIER SCREEN OR
DO NOT TOUCH THE BARRIER SCREEN OR
FIREPLACE WHILE THEY ARE HOT!
FIREPLACE WHILE THEY ARE HOT!
Let the
fi replace cool fi rst before cleaning it.
fi replace cool fi rst before cleaning it.
FOR SAFETY PURPOSE, ensure the barrier
FOR SAFETY PURPOSE, ensure the barrier
screen is re-installed on the fi replace front after
screen is re-installed on the fi replace front after
maintenance if it has been removed.
maintenance if it has been removed.
WARNING
!
Window frame
cover—rear view
Top
11. Slide the mounting frame over the appliance case.
The front of the frame has 4 screws protruding from
it. Fix the frame to the stud mounting panels on
each side of the appliance (3 screws per side).
12. Apply wall fi nish on top of drywall.
IMPORTANT: The drywall is assumed to be
1/2 inch thick.
Wall fi nish material thickness on top of drywall
such as tile, brick, and so on:
When fi nishing under optional 570 Plate:
1/2 inch maximum.
When fi nishing around optional 570 Plate:
see mantel clearances if fi nish protrudes from plate.
Without 570 Plate: 1-1/8 inch maximum.
13. Hook the window trim cover on the top edge of the
window frame.
14. Hook the front trim to the mounting frame placing
its keyholes on the protruding screws on the front
face of the mounting trim and slide it downward to
fi t it.
Maintenance
To clean the front trim, use mild soap and water. You
can dust the screen with a soft brush. To brush the
back of the screen, simply unhook the front trim.
If the barrier becomes damaged, the barrier shall
be replaced with the manufacturer’s barrier for this
appliance.
To clean the window and ceramics inside the fi rebox,
consult the Owner’s Information section of the
Installation and Owner’s Manual supplied with the
fi replace.
DO NOT CLEAN THE GLASS WINDOW WITH
AMMONIA!
