SETUP GUIDE – TPMS
5
SmarTool Setup
These instructions are for rst use only to setup the
SmarTool:
1. In main menu scroll to “System Set” (Item 7/7)
2. Press ENTER
3. Set up units of measure, select “Set Unit” (C/PSI)
4. Press ENTER
5. Default settings are in BAR/Celsius (BC), to switch to
PSI/Fahrenheit (PF) use the up/down arrow
(Figure 3)
6. Press ENTER to select (unit will beep to confirm)
7. Press ESC to return to the Setting screen
8. To set up the number of axles, select “Set Axle”
(Figure 4)
9. Press ENTER
10. Use up down arrow keys to select number of axles
11. Press ENTER once (note: Screen doesn’t change)
12. Press ESC twice to return to Main Menu
*Note: If programming TempTrac, please refer to the
TempTrac Setup Guide.
Figure 4
Figure 3
Setting
Set Unit
Set Axle
Current Unit: PF
Want to Set: BC
