SETUP
GUIDE – TPMS
6
System Setup
The system
setup requires
the following
steps:
1.
Read CANbus ID
2.
Read Sensor ID/Set positions
3.
Format V
alor CANbus memory
4.
Program V
alor CANbus transceiver
5.
Confirm programming
T
urn to next page to begin Step 1.
Pro V2.2
Truck
Figure 5
5
7
Table of Contents
Table of Contents
2
Main Menu
4
Smartool Setup
5
System Setup
6
Sensor
6
Step 1 : Read Canbus ID
7
Step 1.1
7
Vehicle ID
7
Step 1 .2
8
Step 2: Read Sensor ID/Set Positions
9
Step 2.1
10
Step 3: Uploading to Valor Canbus Memory
11
Step 3.1
12
Step 4: Program Valor Canbus Transceiver
13
Step 4.1
14
Step 4.2
14
Step 5: Confirm Programming
15
Step 6: Baseline Setup
16
Step 6.1
16
