17.7 To Remove the Main Burner Injector
See figure 37.
1. Remove the burner - See section 17.6.
2. Remove the burner clamping screw (See
figure 37)
3. Unscrew the injector from the burner
4. Refit in the reverse order.
17.8 To Remove the Appliance from the
Fireplace
1. Remove the burner unit - See section 17.3.
2. If the fire retention is as method 1 (See
section 9.1 of installation instructions), remove
the screws.
If the fire retention is as method 2 (See section
9.2 of installation instructions), slacken the hexagonal adjusters on the cable retainers
and unscrew the thumbscrews to release the cables.
3. Refit as described in the relevant installation sections. Make sure gas soundness,
sealing, spillage test and performance are satisfactory.
18. SHORT LIST OF SPARES
Page 34
INSTALLER GUIDE
Figure 37. Main burner Injector
removal
