Mains voltage Europe: 220 V to 240 V 50 Hz / 60 Hz
North America: 120 V / 60 Hz
Rated power 380 Watt
Machine dimensions
(width x height x length)
390 mm x 240 mm x 530 mm
Usable chamber size
(width x height x length)
310 mm x 100 mm x 310 mm
Maximum size of the foil bag
(width x length)
300 mm x 350 mm
Sealing length 300 mm
Weight approx. 14 kg
Suction power of the vacuum pump The pump reaches - 0.99 bar
at an ambient pressure (mmhG) of - 750.
Airborne sound emission < 85 dB
Ambient temperature + 10 °C bis + 30 °C
Storage temperature - 25 °C bis + 80 °C
Maximum relative ambient humidity during
operation or storage of the machine
85% non-condensing
Requirements for the installation site of the
machine
• Flat surface
• Horizontal surface
• Suicient carrying capacity
Minimum distance to all side walls and to the
rear wall of the machine
100 mm
Free space above the machine 300 mm
