14
Appendix B (cont’d)
UNIT DIMENSIONS
B-4: 12LC AND V12LC WITH RECIRCULATION MODULE (FACTORY INSTALLED)
8.00"
[203]
1.75"
[44]
10.00"
[254]
20.00"
[508]
2.75" [70]
Line Power
Dry Contacts
49.550" [1259]
Strap Mounting
Location
Fresh Air
From Outside
Exhaust Air
From Building
5.125" [130]
Heat Recovery Core
Reversed Door Option
Access Door
15.00"
[381]
Drain Fitting
Access Door
20.000"
[508]
20.000"
[508]
10.000"
[254]
19.207"
[488]
Control Box
NOTE:
For units with the reversed door option, interior components
will appear as a mirror image of the above diagram.
A minimum of 12.00" [305] clearance from any obstruction
is required for removal of control box.
A minimum of 15.00" [381] clearance from any obstruction is required for removal
of heat recovery cores, fans, etc.
The access door can be removed from cabinet with only 2.00" [51] of clearance.
Reversed Door Option
Exhaust Air
To Outside
Fresh Air
To Building
41.24" [1047]
24.50"
[622]
8.00"
[203]
4.00"
[102]
3.53"
[90]
8.00"
[203]
8.00"
[203]
4.00"
[102]
1.75"
[44]
NOTE: Dimensions in [ ] are millimetres.
VK0107A
12.00"
[305]
Control Cover
PTS
12 LC POLY CORE
with recirculation module
12 LC ALUMINUM CORE
with recirculation module
LB.
247
Kg
112
PTS
TOTAL
LB.
269 122
Kg
TOTAL
12 LC ERV HM CORE
with recirculation module
PTS
TOTAL
LB.
260
Kg
120
