vanEE 6LC - Appendix C - Balancing Dampers Position

16
Appendix C
BALANCING DAMPERS POSITION
6LC, V6LC, 12LC AND V12LC
Balancing
Damper
VJ0135A
Canvas Vibration Isolator
Reverse Door Option
Exhaust Air
From Building
Fresh Air
From Outdoors
Min. 8" (203 mm)
(Optional) Canvas Vibration Isolator
Gravity Backdraft Damper
(for recirculation
defrost option only)
Min.12" (305 mm)
Exhaust Air
to Outdoors
Fresh Air
to Building
7000
Balancing Damper
(not supplied)
Canvas Vibration Isolator
Dry Contacts
VJ0123A
