vanEE 6LC - Page 25

25
Appendix H (cont’d)
WIRING DIAGRAMS
7000 - Recirculation Defrost (cont’d)
JUMPER SETTINGS
FOR CONTROL BOARD
JU1
JU1
JU1
JU1
JU1
JU1
JU1
A
B
C
D
E
F
G
ON
OFF
OFF
ON
ON
ON
ON
TAGS
CR1029
CR1030
FU2023
UCB1021
XF2024
R2004
SN1030
TB1001
QTY.
2
1
1
1
1
1
1
DESCRIPTION
R
ELAY DPDT 120 VAC 1/2 HP
15 A @ 120 VAC
F
USE 0.5 A AND FUSE HOLDER
FLUSH
MOUNT
PC BOARD
TRANSFORMER
RESISTOR 3.9K
T
HERMISTOR 10K OHMS
SPLITTER BLOCK
CONTROL BOX BOM
VE0345A
1
5
9
13
4
8
12
14
1
5
9
13
4
8
12
14
NOTE: Written numbers on CR1029 and
CR1030 relays may differ from the ones
shown, but the orientation of the relays
must be the same as illustrated.
