VA N NE R INCO R POR A T ED 20-1050CUL INVERTER/CHARGER—OWNER'S MANUAL
3
Specifications
**Note: If GFCI trips and the inverter is in load demand mode the GFCI may not reset until you toggle inverter off and
back on and then you will have 5 seconds to reset GFCI before unit goes back into load demand again or you can disable
load demand via dipswitch, if available.
Inverter
20-1050CUL
Output at 120 VAC RMS (Continuous Power Rating)
1050 Watts
Surge Capacity at 120 VAC (3 sec)
2100 Watts
Input Voltage, VDC
12 VDC, Nominal
(Deep Cycle Battery Recommended)
10.5 VDC min., 16.0 VDC max.
Output Voltage
120 VAC ± 5%
DC Current Draw (Battery)
OFF
0.017 Amps Typical
Load Demand (waiting)*
0.09 Amps Typical
Full ON at No Load
0.7 Amps Typical
Full ON with Load
Approx. AC Load Watts ÷ 10 or AC Load Amps x 12
Frequency
60 Hz ± 0.1%
Output Wave Form
Modified Sine Wave
Battery Charger
Charging Capacity*
55 Amps (High)
15.0 Amps (Low)
Input Voltage
120 VAC ± 10%
Input Current
8.0 Amps
Bulk Voltage*
14.2 VDC (flooded), 14.1 VDC (gel)
Float Voltage*
13.2 VDC (flooded), 13.6 V (gel)
Bypass Transfer
Output Current, GFCI Outlet**
12 Amps
Other Specifications
AC Input Termination
Hardwire Box, or 3ft. Line Cord
AC Output Termination
Duplex GFCI Receptacle
Ambient Temperature
-20° to +110°F, -29° to +43.4°C
Cooling Air
Fan Cooled, 30 cfm
Chassis
Aluminum
Dimensions
11.57”W x 5.94”H x 11.04”D
Weight
22 lbs
*Determined by Setup Switch setting on front panel.
