Table 1.2 Product component list
Component
Function
AC power cord
Detachable AC power cord. Plug end varies with country
in which Power Source is used to provide AC power
connection to the country-specific AC power source. To
disconnect the power from the generator, disconnect the
power supply cord set from the ac inlet.
The length power supply cord set used shall not be greater
than 3 m.
The power supply cord set used shall be a certified and
appropriate type for an intended market”
AC power switch
Turns AC power “│” (on) or “O” (off). Rocker-type switch
located on the rear of the power source.
Power input receptacle and fuse
holder
Located at the rear of the generator/controller. Connects
the power source to detachable AC power cord and houses
the user-replaceable fuses.
Model 4161 thin wall remote
sealing head
Seals 1/16″ – 3/32″ wall thickness tubing, 1/2″ diameter
max
Model 4162 thick wall remote
sealing head
Seals 1/8″ wall thickness tubing, 1″ diameter max
Sealing head jaws
Dual plated heating mechanism, connected to the
generator/controller by the cable assembly, which performs
a tube seal.
Serial and fuse labels
Located on the back of the generator/controller. Indicates
the model number, the serial number, and the required
power input to the sealer.
Air supply in
Provides air supply for cooling the sealing head jaws and
tubing after a seal has occurred. Located at the rear of the
generator/controller beside the power input receptacle and
fuse holder. The unit also has a built-in compressor for
cooling (low capacity).
Air supply out
Port for the model 4161 or 4162 sealing head ¼″ (outer
diameter) air supply tube that attaches to the
generator/controller. Located on the front of the
generator/controller.
Electrical cable connector
Port for the model 4161 or 4162 sealing head electrical
cable to attach to the generator/controller. Located on the
front of the generator/controller.
