Vante ® Model 4160
14
2.3.3. The main control screen allows users to adjust the process parameters for each
recipe. See numbers 1 – 8, above. When a user changes a parameter, he or she
must confirm the change before the modified process can run. Press the check
button to confirm changes; press the X button to restore the existing parameter
values. See Figure 2.4.
Figure 2.4 Confirm or cancel recipe changes
2.4. Cycle Interrupt Indicator
WARNING: Do not open the sealing head after a cycle is interrupted. The seal may be
incomplete, and the user risks a fluid spill and contamination of the fluid.
2.4.1. If power is not restored to the system, secure the tubing in a manner that will
prevent any fluid spill. Carefully open the sealing head and remove the tubing.
2.4.2. If power is restored, the interrupt indicator activates when the system powers
on. The screen displays the following alarm: “WARNING: PREVIOUS
CYCLE LOST TO POWER FAILURE.”
2.4.3. If power is supplied to the system, press Start on the main control screen or
press and hold the green button on the sealing head for 3 seconds to initiate
the sealing cycle. After the sealing cycle completes, open the sealing head to
remove the tubing.
