Vante ® Model 4160
1
1. Product Overview
1.1. Overview
The Model 4160 TPE sealer generator includes a controller which, when coupled with the Model
4161 or Model 4162 sealing head, will provide automated sealing for a wide variety of
thermoplastic materials and sizes.
This sealing system is intended for use by personnel, trained by their organization in using this
equipment to seal thermoplastic elastomer (TPE and PVC) tubing or parts in a controlled
environment.
Vante devices meet or exceed appropriate electric safety standards and pose no electrical shock
hazard when used with properly fused and grounded outlets.
NOTE: “Sealer/generator” refers to the model 4160. “Sealing head” refers to the models
4161 and 4162.
Table 1.1 Product specifications
Manufacturer name
Vante®
Device name
TPE Tube Sealer
Mechanical
Dimensions
15.2 × 10.9 × 6.4 in. (38.6 × 27.7 × 16.2 cm)
13 × 2.75 × 2.25 in. (33 × 7 × 5.7 cm)
12.3 × 2.75 × 2.25 in (31.2 × 7 × 5.7 cm)
Controller: 4160
Sealing Head: 4162
4161
Operating weight:
14 lbs. (6.3 kg)
Shipping weight:
20 lbs (9 kg)
Electrical
Power Input
100VAC +/-10% 50/60 Hz 4A
115VAC +/-10% 50/60 Hz 4A
230VAC +/-10% 50/60 Hz 2A
Fuses
2 × 250 VAC, 5 × 20 mm T4A
2 × 250 VAC, 5 × 20 mm T4A
2 × 250 VAC, 5 × 20 mm T2A
Power output
< 200 watts DC
Air Supply Requirements
Clean, dry, regulated and filtered constant pressure air source
Line pressure( regulated)
90 psi (max)
CFM (min)
5 CFM
