ProStar 430 Autosampler Control Manual - 14 - 03-914947-33:2
Press the button to display the System Control Method
Advanced Tools window:
to send the current method to the instrument.
to get the active method from the instrument.
to print the current method.
Click on the
button to display the Varian ProStar 430
control method sections. It contains four sub-sections: Injection,
Timed Events and Automix or User program. The User program
sub-section appears when this option is selected in the Injection
sub-section, Injection mode parameter. Click on the required
sub-section to define the corresponding parameters that will be
used during the chromatographic run. The toolbar enables to
easily scroll through the control method windows:
to select the first window of the control method.
to move back to the previous window of the control
method.
to move forward to the next window of the control method.
to select the final window of the control method.
